IP67 LED Inground Light
Housing: 12# Die-casting grey powder coated aluminum. T=60-80µm,
Adhesion of ISO class 1/ASTM class 4B
Front ring: Stainless steel SUS 316L#
Light Window: Step tempered glass.T=8mm
Glass pressure capacity: Full area=2578kgs
Reflector: Optical Reflector efficiency≥90%
Cable gland: IP-68 PG-9 PVC
LED: Multi chip on board LED
PCB: Excellent heat conductivity aluminum,coefficient of heat, Conductivity≥2.0w /mk
Driver: Constant current output
Operating temperature: -20℃~40℃
Power cable: H05RN-F 2×1.0mm2 L=0.5M (low voltage)
H05RN-F 3×1.0mm2 L=0.5M (high voltage)
Mounting sleeve: PVC
IP67 LED Inground Light
12# die-casting grey powder
coated aluminum . T=60-80µm.
Adhesion of ISO class
1/ASTM class 4B
Front cover： Hard chrome-plated stainless steel SUS 316L#
Light Window： Tempered frosted step glass.T=8mm
Reflector： Optical Reflector efficiency≥90%
LED： NICHIA SMD3030 type LED
Cable gland： IP-67 copper and nicked coated
Gasket： Molding shaped seal
LED Driver： Constant current output ,Constant Current Output
Operating temperature： -20℃~40℃
Power cable： H05RN-F 2X1.0mm2 L=0.5m(low voltage)
H05RN-F 3X1.0mm2 L=0.5m(high voltage)
Mounting sleeve： ABS
.png)
IP67 LED Inground Light
Housing : 12# Die-casting grey powder coated aluminum. T=60-80µm .
Adhesion of ISO class 1/ASTM class 4B
Front ring: Stainless steel (SUS 304#, 316# optional)
Glass: Step tempered glass. T=7mm
Loading capacity: Exert force area of Φ10=615kgs
Reflector: Optical Reflector efficiency≥90%
Cable gland: IP-68 PG-9 PVC
Gasket: Molding shaped silicone seal
LED: Multi chip on board LED
Driver: Constant current output
Operating temperature: -20℃~40℃
Power cable: 24V: Input: L=0.5M H05RN-F 2×1.0mm2
100/240V: L=0.5M H05RN-F 3×1.0mm2
Mounting sleeve: PVC
IP67 LED Inground Light
Housing: 12# Die-casting grey powder coated
aluminum .T=60-80µm. Adhesion of
ISO class 1/ASTM class 4B
Front ring: Stainless steel 316L#
Light Window: Step tempered clear glass. T=8mm
Glass pressure capacity: Full area=2274kgs
Lens: Optical lens, efficiency≥85%
Cable gland: IP-68 PG-9 PVC
Gasket: Molding shaped silicone seal
LED Driver: Constant Voltage Input,Constant Current Output
Operating temperature: -20℃~40℃
Power cable: H05RN-F 4X0.75mm2 L=0.5m
Mounting sleeve: PVC
IP67 LED Inground Light
Housing: 12# Die-casting grey powder
coated aluminum. T=60-80µm
Adhesion of ISO class
1/ASTM class 4B
Front ring: Stainless steel 316L#
Glass: Step tempered glass.T=8mm
Glass pressure capacity: Full area=2578kgs
Lens: 3 in 1 optical lens, efficiency≥85%
Cable gland: IP-68 PG-9 PVC
PCB: Excellent heat conductivity
aluminum,coefficient of heat
Conductivity≥2.0w /mk
Operating temperature: -20℃~40℃
Power cable: H05RN-F 2X1.0mm2 L=0.5m (low voltage)
H05RN-F 3X1. 0mm2 L=0.5m (high voltage)
Mounting sleeve: PVC
Dimmable Surpport:Triac PWM 1-10V Dali
.png)
IP67 LED Inground Light
Housing: 12# Die-casting grey powder coated
aluminum . T=60-80µm.Adhesion of
ISO class 1/ASTM class 4B
Front cover: Hard chromeplated stainless steel SUS 316#
Lens: Optical lens, efficiency≥85%
Glass: Step tempered glass. T=7mm
Glass pressure capacity: Full area=1704kgs
Gasket: Molding shaped silicone seal
Operating temperature: -20℃~40℃
Power cable: H05RN-F 2X1.0mm2 L=0.5m(low voltage)
H05RN-F 3X1.0mm2 L=0.5m(high voltage)
Mounting sleeve: PVC
Dimmable Surpport:Triac PWM 1-10V Dali
IP67 LED Inground Light
Housing: 12# Die-casting grey powder
coated aluminum. T=60-80µm
Adhesion of ISO class
1/ASTM class 4B
Front ring: Stainless steel 316L#
Glass: Step tempered glass.T=8mm
Glass pressure capacity: Full area=2578kgs
Lens: 3 in 1 optical lens, efficiency≥85%
Cable gland: IP-68 PG-9 PVC
PCB: Excellent heat conductivity
aluminum,coefficient of heat
Conductivity≥2.0w /mk
Operating temperature: -20℃~40℃
Power cable: H05RN-F 2X1.0mm2 L=0.5m
(low voltage)
H05RN-F 3X1. 0mm2 L=0.5m
(high voltage)
Mounting sleeve: PVC 015#
Dimmable Surpport:Triac PWM 1-10V Dali
IP67 LED Inground Light
Housing: 12# Die-casting grey powder coated
aluminum(RAL432U) .T=60-80µm.
Adhesion of ISO class 1/
ASTM class 4B
Front cover: Stainless steel 316#
Loading capacity: >2000kg
Cable gland: Molding shaped silicone seal
Operating temperature: -20℃~40℃
Mounting sleeve: ABS
Power cable:
H05RN-F 2X1.0mm2 L=0.5m(low voltage)
H05RN-F 3X1.0mm2 L=0.5m(high voltage)
Dimmable Surpport:Triac PWM 1-10V Dali
.png)
IP67 LED Inground Light
Housing: 12# Die-casting grey powder coated
aluminum .T=60-80µm.
Front cover: Stainless steel SUS 316L#
Glass: Step tempered glass. T=8mm
Glass pressure capacity: Full area=3251kgs
Cable gland: IP-68 PG-9 PVC
Gasket: Molding shaped silicone seal
PCB: Excellent heat conductivity aluminum,
coefficient of heat
Conductivity≥2.0w/mk
LED Driver: Constant Voltage Input,Constant Current Output
Operating temperature: -20℃~40℃
Power cable: H05RN-F 4X0.75mm2 L=0.5m
Mounting sleeve: ABS
.jpg)
IP67 LED Inground Light
Housing: 12# Die-casting grey powder
coated aluminum . T=60-80µm.
Adhesion of ISO class
1/ASTM class 4B
Front ring: Stainless steel SUS 316L#
Lens: Optical lens, efficiency≥85%
Glass: Step tempered glass. T=8mm
Glass pressure capacity: Full area=3118kgs
Gasket: Molding shaped silicone seal
Operating temperature: -20℃~40℃
Power cable: H05RN-F 2X1.0mm2 L=0.5m
(low voltage)
H05RN-F 3X1. 0mm2 L=0.5m
(for Single color/high voltage)
Mounting sleeve: Power coated iron
T=1.5mm
.png)
IP67 LED Inground Light
XC-D2FU0110
Housing: 12#Die-casting grey powder
coated aluminum
T=60-80µm. Adhesion of ISO class
1/ASTM class 4B
Front ring: Stainless steel SUS 316L#
Glass: Tempered glass. T=6mm
Glass pressure capacity: Full area=1920kgs
Cable gland: IP-68 PG-9 copper and nickel coated
Gasket: Molding shaped silicone seal
Power cable: H05RN-F 3X1.0mm² L=0.5m
(for Single color)
Mounting sleeve: PVC
