IP68 Stainless Steel LED Fountain Light
Housing: Hard chromeplated molding shaped
stainless steel SUS 316L #
Light Window: Step tempered glass.T=10mm
Gasket: Silicone gasket
Cable gland: IP-68 PG-11 copper with nickel-coated
PCB: Excellent heat conductivity aluminum.
coefficient of heat Conductivity≥2.0w/mk
LED Driver: Constant Voltage Input,
Constant Current Output
Power Cable: H07RN-F 2X1.0mm 2 L=3.0m
Application environment: Temperature of water between
-20˚C~40˚C less than 1 meter depth.
Dimmable Support: Triac PWM 1-10V Dali
IP68 Stainless Steel LED Fountain Light
Housing: Hard chromeplated molding shaped
stainless steel SUS 316L #
Light Window: Step tempered glass.T=10mm
Gasket: Silicone gasket
Cable gland: IP-68 PG-11 copper with nickel-coated
PCB: Excellent heat conductivity aluminum.
coefficient of heat Conductivity≥2.0w/mk
LED Driver: Constant Voltage Input,
Constant Current Output
Power Cable: H07RN-F 2X1.0mm 2 L=3.0m
Application environment: Temperature of water between
20˚C~40˚C less than 1 meter depth.
Dimmable Support: Triac PWM 1-10V Dali
IP68 Stainless Steel Swimming pool Light
Front cover & Housing： Hard chromeplated molding shaped stainless steel SUS 316#
Front plate：Hard chromeplated stainless
steel SUS 316L #
Light Window：Step tempered glass.T=9mm
Gasket：Silicone Gasket
Lens：Optical lens,efficiency≥85%
PCB：Excellent heat conductivity aluminum.
coefficient of heat Conductivity≥2.0w/mk
LED Driver：Constant Voltage Input, Constant Current Output
Power Cable：H07RN-F 2X1.0mm2 L=3.0m
Application environment：Temperature of water between
-20˚C~40˚C less than 1 meter depth.
Cable gland：IP-68 PG-11 copper with nickel-coated
Mounting sleeve：ABS
Dimmable Support：Triac PWM 1-10V Dali
.png)
IP68 Stainless Steel Swimming pool Light
Housing: Hard chromeplated molding shaped
stainless steel SUS 316L #
Front cover: Hard chromeplated stainless
steel SUS 316L#
Light Window: Step tempered glass.T=10mm
Gasket: Silicone gasket
Cable gland: IP-68 PG-11 copper with nickel-coated
PCB: Excellent heat conductivity aluminum.
coefficient of heat Conductivity≥2.0w/mk
LED Driver: Constant Voltage Input,
Constant Current Output
Power Cable: H07RN-F 2X1.0mm 2 L=3.0m
Application environment: Temperature of water between
-20˚C~40˚C less than 1 meter depth.
Dimmable Support: Triac PWM 1-10V Dali
IP68 Stainless Steel Swimming pool Light
Front cover&Housing: Molding shaped sus 316L#
stainless steel
Light Window: Step tempered glass. T=10mm
Gasket: Silicone Gasket
PCB: Excellent heat conductivityaluminum,
coefficient of Heat Conductivity≥2.0w/mk
Cable gland: IP-68 PG-11 copper wiht nickel-coated
LED Driver: Constant Voltage Input,
Constant Current Output
Power cable: H07RN-F 2X1.0mm2 L=3.0m
Application environment: Temperature of water between
-20℃~40℃ less than 1 meter depth.
Mounting sleeve: 060# PVC
Dimmable Support: Triac PWM 1-10V Dali
IP68 Stainless Steel Swimming pool Light
Front cover&Housing: Molding shaped sus 316L#
stainless steel
Light Window: Step tempered glass. T=10mm
Gasket: Silicone Gasket
PCB: Excellent heat conductivityaluminum,
coefficient of Heat Conductivity≥2.0w/mk
Cable gland: IP-68 PG-11 copper wiht nickel-coated
LED Driver: Constant Voltage Input,
Constant Current Output
Power cable: H07RN-F 2X1.0mm2 L=3.0m
Application environment: Temperature of water between
-20℃~40℃ less than 1 meter depth.
Mounting sleeve: 060# PVC
Dimmable Support: Triac PWM 1-10V Dali
IP68 Stainless Steel Swimming pool Light
Front cover&Housing: Molding shaped sus 316L#
stainless steel
Light Window: Step tempered glass. T=10mm
Gasket: Silicone Gasket
PCB: Excellent heat conductivityaluminum,
coefficient of Heat Conductivity≥2.0w/mk
Cable gland: IP-68 PG-11 copper wiht nickel-coated
LED Driver: Constant Voltage Input,
Constant Current Output
Power cable: H07RN-F 2X1.0mm2 L=3.0m
Application environment: Temperature of water between
-20℃~40℃ less than 1 meter depth.
Mounting sleeve: 060# PVC
Dimmable Support: Triac PWM 1-10V Dali
IP68 Stainless Steel Swimming pool Light
Front cover&Housing: Molding shaped sus 316L#
stainless steel
Light Window: Step tempered glass. T=10mm
Gasket: Silicone Gasket
PCB: Excellent heat conductivityaluminum,
coefficient of Heat Conductivity≥2.0w/mk
Cable gland: IP-68 PG-11 copper wiht nickel-coated
LED Driver: Constant Voltage Input,
Constant Current Output
Power cable: H07RN-F 2X1.0mm2 L=3.0m
Application environment: Temperature of water between
-20℃~40℃ less than 1 meter depth.
Mounting sleeve: 060# PVC
Dimmable Support: Triac PWM 1-10V Dali
